94 ZYT series DC Motor
| Model | Terminal Voltage (VDC) | No Load Amps | No Load RPM | Rated Load Torque (N·m) | Rated Load Amps | Rated Load RPM | Body Length (mm) |
|---|---|---|---|---|---|---|---|
| 94ZYT002 | 24 | 3.2 | 4900 | 1 | 24.5 | 4400 | 170 |
| 94ZYT006 | 24 | 3.5 | 5250 | 1.23 | 32.6 | 4570 | 170 |
| Model | Terminal Voltage (VDC) | No Load Amps | No Load RPM | Rated Load Torque (N·m) | Rated Load Amps | Rated Load RPM | Body Length (mm) |
|---|---|---|---|---|---|---|---|
| 94ZYT002 | 24 | 3.2 | 4900 | 1 | 24.5 | 4400 | 170 |
| 94ZYT006 | 24 | 3.5 | 5250 | 1.23 | 32.6 | 4570 | 170 |
