90 ZYT series DC Motor
| Model | Terminal Voltage (VDC) | No Load Amps | No Load RPM | Rated Load Torque (N·m) | Rated Load Amps | Rated Load RPM | Body Length (mm) |
|---|---|---|---|---|---|---|---|
| 90ZYT001 | 24 | 3.0 | 5300 | 0.8 | 23.0 | 4700 | 154.5 |
| 90ZYT001-1 | 24 | 3.0 | 5300 | 0.8 | 25.0 | 4800 | 154.5 |
| 90ZYT001-2 | 24 | 0.6 | 2100 | 0.51 | 5.5 | 1700 | 154.5 |
| 90ZYT004 | 12 | 3.5 | 2000 | 1.2 | 25.0 | 1500 | 199.5 |
| 90ZYT005 | 12 | 4.0 | 5500 | 0.58 | 30.0 | 3800 | 154.5 |
| 90ZYT005-1 | 24 | 1.2 | 4200 | 1.0 | 20.5 | 3546 | 154.5 |
