76 ZYT series DC Motor
| Model | Terminal Voltage (VDC) | No Load Amps | No Load RPM | Rated Load Torque (N·m) | Rated Load Amps | Rated Load RPM | Body Length (mm) |
|---|---|---|---|---|---|---|---|
| 76ZYT007 | 12 | 2.6 | 3850 | 0.4 | 16.0 | 3200 | 133.5 |
| 76ZYT008 | 24 | 0.9 | 3200 | 0.12 | 2.3 | 3088 | 115 |
| Model | Terminal Voltage (VDC) | No Load Amps | No Load RPM | Rated Load Torque (N·m) | Rated Load Amps | Rated Load RPM | Body Length (mm) |
|---|---|---|---|---|---|---|---|
| 76ZYT007 | 12 | 2.6 | 3850 | 0.4 | 16.0 | 3200 | 133.5 |
| 76ZYT008 | 24 | 0.9 | 3200 | 0.12 | 2.3 | 3088 | 115 |
