63 ZYT series DC Motor

63 ZYT series DC Motor
Model Terminal Voltage No Load Data Rated Load Data Body Length (mm)
(VDC) Amps RPM N-m Amps RPM
63ZYT001 36 0.3 3500 0.3 3.5 2800 110
63ZYT015 90 0.15 3470 0.25 1.28 2784 100
63ZYT026 24 0.6 4000 0.4 7.0 3000 100
