60 ZYT series DC motor
| Model | Terminal Voltage | No Load Data | Rated Load Data | Body Length (mm) | |||
|---|---|---|---|---|---|---|---|
| (VDC) | Amps | RPM | N-m | Amps | RPM | ||
| 60ZT009 | 36 | 0.4 | 3550 | 0.3 | 3.5 | 2950 | 120 |
| 60ZYT009-1 | 24 | 0.35 | 3875 | 0.3 | 5.6 | 3150 | 120 |
| Model | Terminal Voltage | No Load Data | Rated Load Data | Body Length (mm) | |||
|---|---|---|---|---|---|---|---|
| (VDC) | Amps | RPM | N-m | Amps | RPM | ||
| 60ZT009 | 36 | 0.4 | 3550 | 0.3 | 3.5 | 2950 | 120 |
| 60ZYT009-1 | 24 | 0.35 | 3875 | 0.3 | 5.6 | 3150 | 120 |
