PM DC Motors
55 ZYT series DC motor
Main applications: Printers, engraving machines, medical equipment, stage lighting and textile machinery.
| Model | Terminal Voltage | No Load Data | Rated Load Data | Body Length (mm) | |||
|---|---|---|---|---|---|---|---|
| (VDC) | Amps | RPM | N-m | Amps | RPM | ||
| 55ZYT001 | 30 | 0.3 | 1800 | 0.15 | 1.2 | 1400 | 74 |
| 55ZYT002 | 24 | 0.4 | 3600 | 0.15 | 2.7 | 3000 | 74 |
