45ZYT series DC Motor
| Model | Terminal Voltage | No Load Data | Rated Load Data | Body Length (mm) | |||
|---|---|---|---|---|---|---|---|
| (VDC) | Amps | RPM | N-m | Amps | RPM | ||
| 45ZYT001 | 24 | 0.3 | 4300 | 0.05 | 1.5 | 3700 | 67 |
| 45ZYT002 | 24 | 0.3 | 3600 | 0.06 | 1.5 | 3200 | 67 |
