110 ZYT series DC Motor
| Model | Terminal Voltage (VDC) | No Load Amps | No Load RPM | Rated Load Torque (N·m) | Rated Load Amps | Rated Load RPM | Body Length (mm) |
|---|---|---|---|---|---|---|---|
| 110ZYT006 | 12 | 3 | 1800 | 1.7 | 30.0 | 1500 | 200 |
| 110ZYT007-1 | 12 | 4.9 | 3270 | 1 | 34.6 | 2708 | 200 |
| 110ZYT007-2 | 24 | 2.6 | 3350 | 1.6 | 26.0 | 3072 | 200 |
| 110ZYT008-1 | 48 | 2.5 | 3560 | 1.6 | 14.3 | 3304 | 200 |
| 110ZYT008-2 | 48 | 2.5 | 3560 | 1.6 | 14.3 | 3304 | 200 |
